AEROCOOL CS-105 BLUE
Online Shop in Thailand
Stylish front panel
The brushed aluminum front panel gives the case a unique and modern look.
The cover of acrylic material in the lower half of the front panel allows to see clearly the internal fan of 12 cm.
Acrylic side window
It incorporates an acrylic window side to show the interior of your platform for all to see.
Air cooling
Supports air cooling in the front, back and side to improve the performance of the cooling system.
Made for high performance
Supports CPU cooler up to 148 mm in height.
Supports additional graphics cards of superior quality up to 320 mm.
Practical access to your media
Quick and easy access to a USB 3.0 port, a USB 2.0 port, the HD microphone and audio ports, and the power and reset buttons.
Storage capacity
External: 1 x bay for 5.25 “units
Internal: Compatible with 2 3.5 “hard drives and a 2.5” SSD or 1 3.5 “hard drive and two 2.5” SSDs
Specifications
| Model | CS-105 Blue |
| Type of box | Mini tower |
| Colour | Black |
| Structure material | SPCC |
| Front panel material | ABS + Acrylic |
| Steel thickness | 0.5mm |
| Motherboards | Micro ATX / mini-ITX |
| Dimensions of the box (internal) | 175 x 350 x 325 mm (W x H x D) |
| Box dimensions (general) | 187 x 361 x 355 mm (W x H x D) |
| Bays 5.25 “ | one |
| Bays 3.5 “ | 2 (1 with 2 of 2.5 “) |
| 2.5 “bays | 1 (2 with 1 of 3.5 “) |
| Expansion slots | 4 |
| GPU space | Supports GPU up to 320 mm |
| CPU space | Supports CPU up to 148 mm |
| Ports I / O | USB3.0 x 1 | USB2.0 x 1 | HD Audio & Mic. |
| Air cooling |
Front: 120 mm or 140 mm x 1 (including 120 mm fan) Rear: 80 mm x 1 (optional) |
| Liquid cooling | Front: 120 mm radiator (optional) |
| Net weight gross weight | 2.31 kg / 2.86 kg |
| Power supply | ATX PSU (optional) (upper) |
| Depth for management of internal cables | 29mm |
