COUGAR MG110

Compact size with large interior
Space to Showcase Your Powerful System

COUGAR MG110-W is a compact micro case with a transparent acrylic side window design, which provides you with enough space for high-end hardware and expansion to showcase your powerful Systems directly. In addition, it supports an up to 240mm water cooling radiator and fivr fans for superior cooling performance. MG110-W micro case provides you customization and powerful gaming System.

Online Shop in Thailand

Description

Transparent Side Window

The transparent window acts as a portal into your gaming PC. It not only allows you to enjoy the lighting effects but also provides you with a remarkable visual experience. If you are Proud of your amazing builds, do not hesitate to show it off.

Superior Cooling Performance

Powerful Airflow ＋ Water Cooling Support ＋ Intelligent Cable Management. In order to optimize ventilation of your high-end inner System by powerful airflow. MG110-W supports an up to 240mm water cooling radiator at front panel and up to five fans. Additionally, the cable routing design keeps all the cables behind the motherboard tray, allowing unobstructed airflow to be unobstructed to dissipate the heat of internal components.

Water cooling radiator support

COUGAR MG110-W

Air cooling support (side fans only in MG110)

COUGAR MG110-W

Air cooling support (side fans only in MG110)

COUGAR MG110-W

Excellent Expandability

MG110-W supports up to 350mm full-sized graphics cards, which allows you to install sufficient computing power you need, while the possibility to host up to 2.5” SSD x 3 or 3.5” HDD x 3 storage devices will provide plenty of space for your files.

Specifications

Model Name		MG110
Case Form Factor		Mini Tower
Dimension (WxHxD)		198 x 378 x 411 (mm) 7.79 x 14.88 x 16.18 (in)
Motherboard Support		Mini ITX/Micro ATX
5.25″ Drive Bay		1
3.5″ Drive Bay		3
2.5″ Drive Bay		3
I/O Panel		USB3.0x1/USB2.0x1,Micx1,Audiox2
Maximum Number of Fans		5 max.
CoolingSystem	Front	120mm Fan x 2
	Top	120mm Fan x 2
	Rear	120mm x 1
	Bottom	None
	Side	None
Water Cooling Support	Front	240mm
	Top	None
	Rear	120mm x 1
	Bottom	None
	Side	None
Fan Pre-installed	Front	None
	Rear	120mm x 1
Cable Management		Yes
Expansion Slots		4
Max. Graphics Card Length		350 (mm) / 13.77 (in)
Max. CPU Cooler Height		150 (mm) / 5.9 (in)
Transparent Side Panel		None
PSU		Standard ATX PS2
Max. PSU Length		160 (mm) / 6.3 (in)
